Danfoss Everflex 07.022-8-8 – PTFE-Schlaucharmatur
€21,65
Zu Produktinformationen springen
Auf Lager
Danfoss Everflex 07.022-8-8 – PTFE-Schlaucharmatur
HOSE NIPPLE ASSY, FC/08, BF/08, CS, STR
Lieferzeit: ca. 2 Wochen
Danfoss Artikelnummer: 07.022-8-8
€25,76
Voraussichtliche Lieferung
19.12.2026
Technische Daten
| Legacy part number | 07.022-8-8 |
| Sub brand | Everflex |
| Brand | Danfoss |
| Inside diameter IN | 0.374 |
| Inside diameter MM | 9.5 |
| Product material | Carbon steel |
| Hose size | -8 |
| Thread size 1 | G 1/2 |
| Angle shape | Straight |
| End size 1 | -8 |
| End Type 1 | Female BSPP swivel |
| Hex size 1 IN | 1.06 |
| Hex size 2 IN | 1.06 |
| Hex size 1 MM | 26.924 |
| Hex size 2 MM | 27 |
| Finish plating | Dura-Kote |
| Construction Style | Crimp |
| A dimension IN | 1.693 |
| Compatible hose ID MM | 12.7 |
| Compatible hoses | 2807 |
| Compatible hose ID IN | 0.5 |
| A dimension MM | 43 |
| End connection torque | 55-70 lb-ft(75-95 Nm) |
| Hose cut off factor IN | 1.232 |
| Hose cut off factor MM | 31.3 |
| Reusable socket hex MM | 22 |
| Product height in | 1.23 |
| Product width in | 1.06 |
| Product width mm | 26.924 |
| Product height mm | 31.242 |
| Product length mm | 53.34 |
| Product length in | 2.1 |
| End connection hex size in | 1.06 |
| End connection hex size mm | 26.924 |
Weitere Produktdaten
- Herkunftsland: Slovakia
- Zolltarifnummer: 73079910
- Danfoss Produktseite: Produkt bei Danfoss
