2H6
€34,24
Zu Produktinformationen springen
Auf Lager
2H6
COUPLING,HK,F,1/4,CS,-6UNF,NBR
Lieferzeit: ca. 2 Wochen
Danfoss Artikelnummer: 2H6
€40,75
Technische Daten
| Certifications | ISO 7241-1 Series B |
| Application | Aerospace Agriculture Chemical Construction Consumer products Fluid transfer Food and beverage General industry Hvac Hydraulics Law enforcement/rescue Medical Military Oil and gas Transportation Trucks |
| Legacy part number | 2H6 |
| Sub brand | Hansen |
| Brand | Danfoss |
| Working pressure max bar | 345 |
| Item type | Female half |
| Valve type | 2 way |
| Product material | Carbon steel |
| Thread size 1 | 9/16-18 UNF |
| Air inclusion max cc | 1.2 |
| Angle shape | Straight |
| Body size | 1/4 |
| Connection style | Manual connect |
| End size 1 | -6 |
| End type 1 | Female ORB port ISO 11926-1 |
| Finish plating | Zinc trivalent |
| Fluid loss cc | 0.9 |
| Hex size 1 IN | 0.88 |
| Hex size 1 MM | 22.352 |
| Latch type | Push/pull |
| Safety locking mechanism | None |
| Seal material | Nitrile (NBR) |
| Working pressure max psi | 5000 |
| Working temperature max C | 121 |
| Working temperature max F | 250 |
| Working temperature min C | -40 |
| Working temperature min F | -40 |
| Fluid compatibility | Hydraulic service |
| Flow rate gpm | 3 |
Weitere Produktdaten
- Herkunftsland: Mexico
- Zolltarifnummer: 84818081
- Danfoss Produktseite: Produkt bei Danfoss
