Danfoss Synflex 9MH04-10N040 – Thermoplast-Schlaucharmatur
HOSE FTG, SS/10, LM/04, CS, 45D
Lieferzeit: ca. 2 Wochen
Danfoss Artikelnummer: 9MH04-10N040
€16,47
Technische Daten
| Legacy part number | 9MH04-10N040 |
| Brand | Synflex by Danfoss |
| Inside diameter IN | 0.16 |
| Inside diameter MM | 4 |
| Product material | Carbon steel |
| Hose size | -4 |
| Angle shape | 45 Degree |
| End size 1 | -4 |
| Drop dimension IN | 0.83 |
| Drop dimension MM | 21.1 |
| Finish plating | Dura-Kote |
| Construction Style | Crimp |
| A dimension IN | 3.04 |
| Compatible hose ID MM | 6.35 |
| Compatible hose ID IN | 0.62 |
| A dimension MM | 77.2 |
| Hose cut off factor IN | 1.95 |
| Hose cut off factor MM | 49.6 |
| Product height in | 1.43 |
| Product width in | 0.81 |
| Product width mm | 20.574 |
| Product height mm | 36.322 |
| Product length mm | 77.216 |
| Product length in | 3.04 |
Weitere Produktdaten
- Herkunftsland: Germany
- Zolltarifnummer: 73269098
- Danfoss Produktseite: Produkt bei Danfoss
