FD15-1000-04
€173,98
Zu Produktinformationen springen
Auf Lager
FD15-1000-04
COUPLING,FD15,C,N/A,CS,-4MNPT,NBR
Lieferzeit: ca. 2 Wochen
Danfoss Artikelnummer: FD15-1000-04
€207,04
Technische Daten
| Compliances | MIL-V-81940/2-1 |
| Application | Construction Lubricating oils Military Stationary equipment |
| Legacy part number | FD15-1000-04 |
| Sub brand | Hansen |
| Brand | Danfoss |
| Working pressure max bar | 21 |
| Item type | Complete |
| Product material | Brass Carbon steel |
| Thread size 1 | 1/4-18 NPTF |
| Angle shape | Straight |
| Burst pressure min bar | 827 |
| Body size | N/A |
| Burst pressure min psi | 12000 |
| End size 1 | -4 |
| End type 1 | Male pipe (NPTF) |
| Finish plating | Corrosion resistant plating |
| Hex size 1 IN | 0.69 |
| Hex size 2 IN | 0.38 |
| Hex size 1 MM | 17.526 |
| Hex size 2 MM | 9.7 |
| Latch type | Screw to connect |
| Seal material | Nitrile (NBR) |
| Working pressure max psi | 300 |
| Working temperature max C | 135 |
| Working temperature max F | 275 |
| Working temperature min C | -54 |
| Working temperature min F | -65 |
| Fluid compatibility | Engine oil Oil Transmission fluid |
| Product length mm | 65 |
| Product length in | 2.56 |
Weitere Produktdaten
- Herkunftsland: USA
- Zolltarifnummer: 84812010
- Danfoss Produktseite: Produkt bei Danfoss
