FD35-1008-06-06
€41,87
Zu Produktinformationen springen
Auf Lager
FD35-1008-06-06
COUPLING,FD35,M,3/8,CS,-6UNF,FKM
Lieferzeit: ca. 2 Wochen
Danfoss Artikelnummer: FD35-1008-06-06
€49,83
Technische Daten
| Application | Hydraulic jacking system Hydraulic tools Hydraulics |
| Legacy part number | FD35-1008-06-06 |
| Sub brand | Hansen |
| Brand | Danfoss |
| Working pressure max bar | 690 |
| Item type | Male half |
| Product material | Carbon steel |
| Thread size 1 | 9/16-18 UNF |
| Angle shape | Straight |
| Body size | 3/8 |
| End size 1 | -6 |
| End type 1 | Female ORB port ISO 11926-1 |
| Finish plating | Zinc trivalent |
| Hex size 1 IN | 0.94 |
| Hex size 1 MM | 23.876 |
| Latch type | Push/pull |
| Safety locking mechanism | Sleeve lock |
| Seal material | Fluorocarbon (FKM) |
| Working pressure max psi | 10000 |
| Working temperature max C | 121 |
| Working temperature max F | 250 |
| Working temperature min C | -34 |
| Working temperature min F | -30 |
| Fluid compatibility | Hydraulic fluid |
Weitere Produktdaten
- Herkunftsland: Mexico
- Zolltarifnummer: 84818081
- Danfoss Produktseite: Produkt bei Danfoss
