1/2

WH004-24MT60

Name: WH004-24MT60
Brand: Danfoss
SKU: WH004-24MT60
Price: 29.64 EUR
Availability: InStock

HOSE-WIN, WH004, -24, 60M, RL, R4

Lieferzeit: ca. 2 Wochen

Danfoss Artikelnummer: WH004-24MT60

€35,27 €35,27/m

Auf Lager

Hinweis für Schlauch- und Meterware: Die tatsächlich gelieferte Länge kann rollen- bzw. fertigungsbedingt um bis zu 5 % von der bestellten Menge abweichen. Größere Bestelleinheiten (z. B. MT50 = 50 m) können auf mehrere Schlauchrollen bzw. Teilrollen aufgeteilt geliefert werden.

Technische Daten

Series	WH004 Series
Bend radius min (mm)	65
Abrasion resistance	Standard
Bend radius min (inch)	2.56
Construction	2 Ply Pes Fab,St Wire,Cu
Certifications	MSHA Approved
Compliances	SAE J517
Application	Fuel gas system
Burst pressure (psi)	600
Burst pressure (bar)	42
Inside diameter (mm)	38.1
Conductivity	Conductive
Inside diameter (inch)	1.5
Lay line style	Ink transfer
Length (in)	2362
Outside diameter (inch)	1.94
Length (mm)	60000
Package form	Reel
Outside diameter (mm)	49.2
Qualified hose fittings	4T
Reinforcement material	Brass plated steel wire
Size	-24
Vacuum rating (inHg)	28
Working pressure max (bar)	11
Vacuum rating (mmHg)	711
Working pressure max (psi)	150
Working temperature max (C)	100
Working temperature max (F)	212
Working temperature min (F)	-40
Working temperature min (C)	-40
Brand	Winner by Danfoss
Color	Black
Cover material	Nitrile (NBR)
Tube material	Nitrile (NBR)
Product height in	1.5
Product width in	1.5
Product width mm	38.1
Product height mm	38.1
Fixed Length	60
